JD 24T and 24WS Twine Baler - Operator's Manual

Product Description
This is Farm Manuals Fast's complete operator's manual for the JD 24 hay baler. Covers both wire and twine versions.
This owner's manual contains information on operating, adjusting, maintaining and troubleshooting for your JD square hay baler.
FREE MANUAL - All Years and Serial Numbers Covered - You are getting two for the price of one! Each manual covers a specific serial number range. We are the only website that sells all together so you don't have to worry about getting about the correct manual version for your machine.
Table of Contents
Specifications
Operation
- How the knot is tied
- Before operation
- Safety precaution
- Operating adjustments
- Machine protective devices
Lubrication
Service
- Trouble shooting
- Service checking
- Needle frame adjustment
- Timing the baler
- Billhook
- Knife arm
- Twine disk
- Twine holder
- Needle adjustments
- Knotter drive brake
- Tucker fingers
- Plungerhead safety stop
- Plungerhead and knife adjustment
- Safety slip clutch
- Auger drive belt
- Chain adjustments
- Timing marks
- Knotter gears
- Bale measuring control
- Gear case
- Pitman
- Engine and belt alignment
Attachments
- Wisconsin engine and mounting
- Power take-off
- Tractor hookup
- No. 2 Bale Ejector
- Oversized tires
- Dual wheels (less tires)
- Pickup gauge wheel
- Wagon hitches and bale chute
- Pickup slip clutch
- Bale counter
- Wiper arm modeling tool
- Compressors
- Tool box
- Side-drop bale chute
Assembly
Manual Details
Pages: 42 pages and 66 pages
Years and Serial Numbers: Covers all years and serial numbers
Models: 24T
Manual Type: Operator's Manual
