JD 40 Bale Ejector Attachment - Operator's Manual

Product Description
This is the complete operator's manual for the JD 40 bale ejector attachment.
This owner's manual contains information on operating, adjusting, maintaining and troubleshooting your JD bale ejector attachment.
Covers All Years and Serial Numbers - Other websites sell manuals that are incomplete or only cover a specific year of the machine. This manual is guaranteed to be complete and to cover your machine's model year and serial number.
Table of Contents
- Safety
- Preparing the Bale Ejector
- Transporting
- Operating the Bale Ejector
- Baling with Bale Ejector
- Ejecting Bales
- Bale Size
- Using Manual Bale Throwing Distance
- Controls
- Using Electric Controls
- Using Hand Trip Lever
- Adjusting Bale Length Timing
- Throwing Frame Latch
- Adjusting Bale Weight
- Adjusting Bale Length
- Using Optional Hydraulic Aiming Control
- Adjusting Bale Case Extensions
- Attachments
- Lubrication and Maintenance
- Troubleshooting
- Miscellaneous
- Hydraulic Pump
- Latch and Throwing Cylinder
- Control Valve
- Electrical
- Service
- Practice Safety
- Adjusting Trip Cam
- Adjusting Trip Lever
- Changing Hydraulic Oil
- Adjusting Pump Drive Belt
- Adjusting Trip Pedal and Extension
- Adjusting Latch Springs
- Wiring Diagram
- Hydraulic System Diagram
- Storage
- Assembly
- Specifications
- Crime Prevention Tips
- Index
Manual Details
Pages: 88
Years and Serial Numbers: Covers all years and serial numbers
Models: 40
Manual Type: Operator's Manual/ Owner's Manual
Need A Repair Manual?
Due to copyright restrictions, we are unable to sell the repair, service, or technical manual for this model.
