JD B, DF-B, and FB-B Grain Drill - Parts Catalog

Name: JD B, DF-B, and FB-B Grain Drill - Parts Catalog
Brand: JD
SKU: SKUPC2025-40
Price: 19.99 USD
Availability: InStock

This is Farm Manuals Fast's complete parts catalog for the JD B, DF-B, and FB-B grain drill.

This parts book contains exploded parts views and product codes for every component of the B, DF-B, and FB-B grain drill. An absolute must if you are rebuilding, taking apart, or purchasing a part for your JD grain drill.

Covers All Years and Serial Numbers - Other websites sell manuals that are incomplete or only cover a specific year of the machine. This manual is guaranteed to be complete and to cover your machine's model year and serial number.

ATTACHMENTS

Agitators, grain

Beet and gauge press wheel

Brome seed boxes

Brome seed feed shafts and drives

kome seed quantity control slides and index adjusting screw

Gang press attachments

Grass seed boxes

Grass seed drive

Grass seed feedshaft

Grass seed and brome seed gear box

Grass seed throw-out

Leveling attachments

Markers, manual

Marker, hydraulic disk

Marker, cylinder, hydraulic disk

Multi-luber for bearings and drives (1" hex, pump —12 ports)

Multi -lube r for furrow openers (1" and 1-1/4" hex pumps—12 ports)

GRAIN BOX AND FRAME PARTS

Acremeter

Agitator, baffl|e and screen, fertilizer

Box, fertilizer

Box, grain {DF-B, FB-B)

Box, grain

Countershaft

Countershaft, fertilizer

Covers, grain and fertilizer box (DF-Bt FB-B)

Covers, grain box

Cover, grain box (B-B, DR-B)

Feed shaft, fertilizer

Feed shaft, grain

Footboards

Frames

Gears, sliding and throw-out

Hitch stand

Hitch, tractor

Land measurer (B-A) (60090-63032)

Pressure shafts (B-A, B-B, DR-A, DR-B)

Shifter and index, grain

Shifter and slide, fertilizer

Stand, jack (20" wheels only)

Wheel and axle support—15" wheels

Wheel and axle support—20" wheels

FURROW OPENERS AND OPENER ATTACHMENTS

Depth bands

Double disk furrow openers (anti-friction bearings)

Double disk furrow openers (hard-iron bearings)

Fertilizer rear distributor attachments

Gage-O-Matic furrow openers (anti-friction bearings)

Separate fertilizer placement attachment (for anti-friction double disk)

Single disk and semi-deep furrow openers (anti-friction bearings)

Single disk and semi-deep furrow openers (hard-iron bearings)

Spring trip hoe furrow openers

LIFTING EQUIPMENT

Adapters, single remote hydraulic cylinder

Adapters and hose supports, single remote hydraulic cylinder

Adapters, dual remote hydraulic cylinder

Helper spring, lift lever

Hose supports, remote hydraulic cylinder

Levers, front lift

Levers, rear lift

Lifts, powe

Pages: 92

Years and Serial Numbers: Covers all years and serial numbers

Models: B, DF-B, and FB-B

Manual Type: Parts Book/ Parts Catalog

Due to copyright restrictions, we are unable to sell the repair, service, or technical manual for this model.
